Modular Data Centers

Modular Data Centers
Modular Data Centers
Product Code : 50
Product Description


Serving the industry for the last 16 years, we have become a renowned manufacturer and exporter of an extensive range Modular Data Centers. These centers are designed using finest quality materials which we source from the authentic vendors. Highly demanded in the commercial and military fields, our Modular Data Centers are available at pocket friendly price. These centers are generally developed in rectangular shape. Our entire assortment is highly appreciated by our clients spread in U.S, Middle East and Europe.

Features:



  • Robust construction

  • Can withstand critical temperature

  • Spacious

  • Quality standard

  • Excellent finish

  • Long lasting construction

  • Less maintenance

Technical Specification

PARTICULAR

SPECIFICATION OR PARAMETER

Bottom Frame

ISMC 100x50mm.

Top Frame

50mm x 50 mm x 2mm thick SHS.

Stiffener Bottom

60mm x 40 mm x 2mm Rectangular Pipe (600 mm Grid).

Stiffener Top

25mm x 25mm x 2mm thick MS Sq Pipes.

Side Post

Square pipes of size 50mm x 50mm x 2mm thick.

Side Wall Stiffeners

40mm x 20mm x 1.6mm thick MS Square Pipe.

Paneling Outside

Specially formed M.S. Corrugated Sheet -1.2mm Thick.

Internal Wall Paneling

9mm pre laminated particle/MDF board.

Roof Outside

M.S. Sheet 1.2mm thick properly sloped and water tight, to form roof.

False Ceiling

9mm Pre Laminated Particle/MDF Board, Plane White.

Bottom Flooring.

18mm cement bonded fiber sheets. (100% water, termite & dimensional proof with 1.2MM Thk vinyl carpet.)

Aluminum Windows - 2 nos. Size - 3’ x 3’

Double Shutter sliding Aluminum Powder coated Windows with 4mm Glass for all windows. Safety grills from outside and monsoon shed on top of the windows

Door - 1 no. Size - 6’6” x 3

Constructed of Rigid Steel Frame with proper locking system.

Insulation

Thermocol Insulation-25mm on sides and 50mm on top.

Wiring

All wiring shall be concealed type & shall be insulated copper wire (FR

grade) of ISI Polycab/Fortune Art/Ronaldo/Finolex.

Electrical Fittings

All electrical fitting in the portable cabin shall be 220 -240 V, AC 50Hz.
1) Tubes lights - 3 nos.
2) Door Light- 1 no.
3) Fan - 2 nos.
4) 5 amp Socket Points - 4 nos.
5) 16 amp A.C Point - 1 no. 6) Earth leakage circuit breaker (ELCB) at the INPUT JUNCTION for additional SAFETY.

Outside Painting

Complete chemical cleaning done on the cabin and painting done with 2 coats of epoxy primer and two coats of Chlorinated Rubber paint - Make ASIAN/BERGER.

Hooks

Specially formed hooks for easy lifting and shifting.
